Dimensions
- dimensions: 4685*1900*1617
- Wheelbase: 2775
- Wheels: 18R
- Weight (Curb Mass): 1720
JF--L7 EV
Intelligent and cost-effective pure electric SUV
Widely used in online taxi hailing services
affordable
Advanced electric drive technology
Colores
JF--L7 EV
affordable:Widely used in online taxi hailing services,Advanced electric drive technology:
JF--L7 EV Specs
Starting at: $
Drive
- Energy: Pure EV
- Range: 518
- Drive:
- Transmission: Automatic transmission
Power
- Battery type: Lithium iron phosphate battery
- Battery Factory:
- Charging: Fast charging time [min]：28
- Battery capacity: 61.2
Cockpit
- Seat: 5
- Displays:
- luggage volume: 413
- Airbag: Fore Two
Performance
- High Speed: 160
- Acceleration: 0
- Intelligent assisted driving: OK
- Air conditioning: OK
Warranty
- Basic Vehicle: Three years or 120000 kilometers
JF--L7 EV
| Basic parameters | ||
| level | JF-L7 EV AIR | JF-L7 EV PRO |
| Energy type | Pure electric | Pure electric |
| Listing time | 2024-09-23 | 2024-09-23 |
| CLTC pure electric range [km] | 518 | 518 |
| Fast charging time [h] | 0.47 | 0.47 |
| Fast charging capacity [%] | 30-80 | 30-80 |
| Electric motors [Ps] | 163 | 218 |
| transmission case | 1st gear fixed gear ratio | 1st gear fixed gear ratio |
| Length * Width * Height [mm] | 4685*1900*1617 | 4685*1900*1617 |
| Vehicle structure | 5-door 5-seater SUV | 5-door 5-seater SUV |
| Maximum speed [km/h]/ | 160 | 170 |
| Length [mm] | 4685 | 4685 |
| Width [mm] | 1900 | 1900 |
| Height [mm] | 1617 | 1617 |
| Wheelbase [mm] | 2775 | 2775 |
| Front wheelbase [mm] | 1605 | 1605 |
| Rear wheelbase [mm] | 1605 | 1605 |
| Door opening method | Swing door | Swing door |
| Number of car doors | 5 | 5 |
| Number of seats | 5 | 5 |
| Approach angle [°] | 17 | 17 |
| Departure angle [°] | 24 | 24 |
| Official trunk capacity [L] | 413 | 413 |
| Curb weight [kg] | 1720 | 1740 |
| Full load mass [kg] | 2134 | 2134 |
| Motor | ||
| Electric motor brand | Zhuhai Yingboer | Zhixin Technology |
| Motor model | TZ180XSS01 | TZ200XS3F0 |
| Number of driving motors | Single motor | Single motor |
| Motor layout | Front end | Front end |
| Motor type |
Permanent magnet synchronization |
Permanent magnet synchronization |
| Total power of electric motor [kW] | 120 | 160 |
| Total horsepower of electric motor [Ps] | 163 | 218 |
| Total torque of electric motor [N · m] | 240 | 310 |
| Maximum power of front motor [kW] | 120 | 160 |
| Maximum torque of front motor [N · m] | 240 | 310 |
|
Battery/Recharge |
||
| battery type |
Lithium iron phosphate battery |
Lithium iron phosphate battery |
| Motor brand |
Wuhan Chu Neng |
China Innovation Airlines |
| Battery Temperature Management |
●Low temperature heating ● Liquid cooling |
●Low temperature heating ● Liquid cooling |
| CLTC pure electric range [km] | 518 | 518 |
| Battery capacity [kWh] | 61.2 | 62.3 |
| Vehicle charging port |
● Slow charging port ● Fast charging port |
● Slow charging port ● Fast charging port |
| Slow charging port location |
● Right rear side of the car |
● Right rear side of the car |
| Fast charging port location | ● Right rear side of the car | ● Right rear side of the car |
| Fast charging time [min] | 28 | 28 |
| Fast charging time [h] | 0.47 | 0.47 |
| External discharge function | ● | ● |
| VTOL external discharge power | ●3.3kW | ●3.3kW |
| transmission case | ||
| Transmission Description | Electric single speed gearbox | Electric single speed gearbox |
| Transmission type | Fixed gear ratio | Fixed gear ratio |
| Number of gears | 1 | 1 |
| Chassis steering | ||
| Driving type | Front wheel drive | Front wheel drive |
| Front suspension type | McPherson independent suspension | McPherson independent suspension |
| Rear suspension type |
Multi link independent suspension |
Multi link independent suspension |
| Assistance type |
Electric power assist |
Electric power assist |
| Wheel braking | ||
| Front brake type |
● Ventilation disc |
● Ventilation disc |
| Rear brake type |
●Solid disc type |
●Solid disc type |
| Parking brake type |
Electronic parking |
Electronic parking |
| Front tire specifications | ●225/60 R18 | ●225/60 R18 |
| Rear tire specifications | ●225/60 R18 | 225/60 R18 |
| Spare tire |
●Only tire repair tools |
●Only tire repair tools |
| Proactive safety | ||
| ABS anti lock braking system | ● | ● |
| Braking force distribution (EBD/CBC, etc.) | ● | ● |
| Brake Assist (BA/EBA/BAS, etc.) | ● | ● |
| Traction control (ASR/TCS/TRC, etc.) | ● | ● |
| Vehicle stability control (ESP/DSC/VSC, etc.) | ● | ● |
| Reminder for not fastening seat belt |
● First row |
● First row |
| Tire pressure monitoring |
● Tire pressure display |
● Tire pressure display |
| Passive safety | ||
| Driver's airbag | ● | ● |
| Passenger airbag | ● | ● |
| First row side airbag | ● | ● |
| Second row side airbags | _ | _ |
| Side safety air curtain | _ | ● |
|
Auxiliary/control configuration |
||
| Rear parking radar | ● | ● |
| Driving assistance imaging |
360 degree panoramic image |
360 degree panoramic image |
| Chassis perspective | ● | ● |
| Cruise control system |
● Cruise control |
● Cruise control |
| Driving mode selection |
● Sports ● Economy ● Standard/Comfortable |
● Sports ● Economy ● Standard/Comfortable |
